M16 Positive Direction Waterproof Connectors IP67 Socket Molding with Cable
Products are available for wholesale and customization
Quantity:
| Number of Poles | 2pin | 3pin | 4pin | 5pin | 6pin | 7pin | 8pin | 2+4 |
| Voltage Rating | 250V | 250V | 250V | 250V | 125V | 50V | 50V | 250V+50V |
| Current Rating | 15A | 15A | 10A | 10A | 5A | 5A | 5A | 10A+3A |
| Wire Section | 0.75mm² | 0.75mm² | 0.5mm² | 0.5mm² | 0.25mm² | 0.25mm² | 0.25mm² | 1.5mm² |
| -1.5mm² | -1.5mm² | -1.0mm² | -1.0mm² | -0.5mm² | -0.5mm² | -0.5mm² | -0.5mm² | |
| Temperature Rating | -40 ℃-105 ℃ | |||||||
| IP Code | IP65/IP67 | |||||||
| Housing Material | high temperature thermoplastic | |||||||
| Contact Material | Gold Plated Copper Alloy | |||||||
Product Features
► Fast self-locking connection method, strong foolproof protection, blind insertion;
► Multi-core product structure, in line with diversified industrial requirements;
► The ground wire is contacted first, and the fire neutral wire is contacted later,
which is safer and more reliable.
► Using high-performance copper alloy, gold-plated, electrical performance guarantee
► High-performance thermoplastic material, high temperature resistance, UV resistance,
fire retardant, explosion-proof, oil-resistant.
Product Application
Street lights
Landscape Lighting
Solar energy
Plant lighting
