5556TL - Connector Terminal, 4.2 mm Pitch, 5556 Series
Products are available for wholesale and customization
Quantity:
Specification:
| Poies | 2~24 |
| ApplicableWires | AWG #22~#18 |
| Operating temperature | -25C~+85°C |
| Voltage Rating | 250V AC/DC |
| Current Rating | 9.0AAC/DC |
| Contact Resistance | ≤20mΩ |
| Insulation Resistance | ≥1000MΩ |
| Withstand Voltage | 1500VAC/minute |
| Housing | Thermoplastic |
| Terminal | Phosphor bronze |
| Wafer | Thermoplastic |
Product Application
Street lights
Landscape Lighting
Solar energy
Plant lighting
